Building a Multi-Node Proxmox Homelab

Overview

Proxmox VE became the foundation of my homelab as I moved from running individual applications on dedicated systems toward managing infrastructure as a collection of virtualized services.

Rather than treating each physical computer as an independent server, I built a multi-node Proxmox environment capable of hosting virtual machines, Linux containers, storage services, monitoring systems, and self-hosted applications.

The project gave me practical experience with virtualization, clustering, shared infrastructure, storage dependencies, backups, networking, and troubleshooting systems that depend on one another.

Goals

The environment was designed around several goals:

Consolidate multiple services onto virtualization hosts
Learn virtual-machine and Linux-container administration
Separate applications into logical workloads
Integrate centralized network storage
Build repeatable backup and recovery workflows
Manage infrastructure from a centralized platform
Allow the environment to expand with additional physical nodes
Gain experience troubleshooting interconnected systems

Architecture

The environment consists of multiple Proxmox VE systems with different infrastructure responsibilities.

A simplified view looks like:

                    Proxmox Environment
                           |
          +----------------+----------------+
          |                                 |
          v                                 v
     Compute Nodes                     Storage Node
          |                                 |
    +-----+------+                          |
    |            |                          v
    v            v                       TrueNAS
   VMs          LXCs                         |
    |            |                          v
    +------+-----+                         ZFS
           |                                |
           +---------------+----------------+
                           |
                           v
                    Homelab Services

Over time, additional nodes have been added, removed, rebuilt, and returned to the environment as the lab has evolved.

That has made the cluster itself a useful learning environment rather than a configuration that was built once and left untouched.

Virtual Machines and Linux Containers

I use both virtual machines and Linux containers depending on the requirements of a service.

Virtual Machines

Virtual machines are useful when a workload benefits from stronger operating-system isolation or requires its own complete environment.

Examples include infrastructure platforms and applications where I want the guest operating system to behave independently from the Proxmox host.

Linux Containers

LXC containers provide a lighter-weight option for many Linux services.

They require fewer resources than a full virtual machine and are well suited for services such as:

reverse proxies
monitoring platforms
utility applications
small web services
infrastructure tools

Choosing between a VM and an LXC has become part of the planning process rather than simply defaulting to one virtualization method.

Infrastructure Roles

One of the biggest changes as the lab developed was moving away from thinking about physical computers as individual machines.

Instead, I began thinking about infrastructure roles.

For example:

Compute
  |
  +-- Proxmox VE
  +-- Virtual machines
  +-- Linux containers

Storage
  |
  +-- TrueNAS
  +-- ZFS
  +-- NFS

Backup
  |
  +-- Proxmox Backup Server

Networking
  |
  +-- OPNsense
  +-- VLANs
  +-- DNS
  +-- VPN

Monitoring
  |
  +-- Prometheus
  +-- Grafana
  +-- Uptime monitoring

This makes the environment easier to reason about because each platform has a specific responsibility.

Network Integration

The Proxmox environment is connected to the segmented homelab network rather than operating on an isolated flat LAN.

This means virtualization depends on the underlying network design for:

management access
DNS
storage connectivity
application access
monitoring
backup traffic
remote administration

This has made Proxmox troubleshooting closely tied to networking.

A VM that appears offline may actually have a problem involving:

the guest operating system
its virtual network interface
the Proxmox bridge
VLAN configuration
the physical switch
OPNsense routing
firewall policy
DNS

Understanding those layers has been one of the most useful parts of operating the environment.

Storage Integration

The virtualization environment is integrated with centralized storage provided by TrueNAS.

Network storage allows Proxmox workloads to use shared capacity without requiring every physical node to contain large amounts of local storage.

This also introduced important dependencies.

For example, if an NFS-backed resource becomes unavailable, the visible problem may initially appear inside Proxmox even though the actual failure exists deeper in the storage or network stack.

The dependency chain can look like:

VM / Container
      |
      v
Proxmox
      |
      v
NFS Mount
      |
      v
Network
      |
      v
TrueNAS
      |
      v
ZFS Pool

This reinforced the importance of troubleshooting infrastructure from the dependency layer upward.

Backups

Virtualization made backup management more structured.

Instead of treating each application as an entirely separate backup problem, Proxmox workloads can be protected using centralized backup infrastructure.

I use Proxmox Backup Server as part of the environment to provide VM and container backup workflows.

This allows me to work with concepts such as:

scheduled backups
retention
datastore management
restore workflows
backup verification
recovery planning

One of the most important lessons from building the lab has been that a backup system is only valuable if recovery is understood as part of the design.

Cluster Management

Operating multiple Proxmox nodes introduced cluster concepts that do not appear in a single-host deployment.

These include:

node membership
quorum
cluster communication
workload placement
configuration synchronization
node removal
node re-addition
recovery after failed or unavailable members

The environment has gone through changes where nodes were temporarily removed and later returned to service.

Working through those situations provided more useful experience than simply creating a cluster and never modifying it.

Troubleshooting Node Changes

Cluster membership can create dependencies that are easy to overlook.

For example, removing or losing a node affects more than whether that specific computer is online.

It can affect:

quorum
cluster commands
configuration state
monitoring
storage references
service documentation

When making changes, I learned to check the wider environment rather than treating node removal as an isolated event.

Monitoring

The Proxmox nodes are also part of the homelab monitoring environment.

Metrics are collected so I can visualize host health and resource utilization from a centralized Grafana dashboard.

Areas I monitor or plan to expand include:

CPU usage
memory utilization
filesystem capacity
network throughput
node availability
load
storage health
service availability

Monitoring multiple nodes from one platform is significantly more useful than logging into each system independently to check its current state.

Why Proxmox

Proxmox has been particularly useful as a learning platform because it combines several infrastructure concepts in one environment.

Working with it has required me to understand more than virtualization alone.

The platform touches:

Linux administration
networking
storage
clustering
backups
permissions
services
monitoring
hardware

That makes it a strong foundation for experimenting with infrastructure while still requiring me to understand the systems underneath the web interface.

Problems and Rebuilds

The environment has not remained static.

Nodes have been rebuilt, storage configurations have changed, services have moved between systems, and cluster membership has evolved.

Although those changes occasionally create more work, they are also where much of the learning happens.

A system that never changes provides fewer opportunities to understand recovery.

Rebuilding a node forces questions such as:

What configuration actually matters?
What services depended on this host?
Where are the backups?
Which network settings must be recreated?
What monitoring needs to be updated?
What cluster state needs to be cleaned up?
What documentation is now outdated?

Those questions are useful beyond Proxmox itself.

What I Learned

Building and maintaining the Proxmox environment taught me several important infrastructure concepts:

Virtualization is only one layer of a larger system
Containers and VMs each have appropriate use cases
Storage and networking failures can appear as virtualization failures
Cluster membership introduces operational dependencies
Backups need tested recovery workflows
Monitoring becomes more important as the number of systems increases
Documentation matters when infrastructure changes
Rebuilding systems exposes assumptions that normal operation can hide

Most importantly, the project shifted my thinking from administering individual computers to understanding how multiple systems combine to provide infrastructure.

Current Status

Proxmox remains the primary virtualization platform in my homelab.

The environment has continued to evolve beyond its original multi-node deployment, including additional compute capacity, centralized storage, monitoring, backup infrastructure, and nodes that have been rebuilt or returned to the cluster.

Rather than considering the platform a finished one-time project, I treat it as the foundation on which the rest of the homelab continues to develop.

Technologies Used

Proxmox VE
Debian Linux
KVM/QEMU
LXC
Proxmox clustering
Proxmox Backup Server
TrueNAS
ZFS
NFS
VLAN networking
Prometheus
Grafana
